Double Sided Aluminum Tape with Film

Basic Info

Model NO.	0.1*535
Alloy State	O-State
Production Technology	Composite Technology
Use	Armoured Cable
Transport Package	Wooden Pallet Loading
Specification	100*100
Trademark	CF
Origin	Jiangsu, China
HS Code	7607200000
Production Capacity	12, 000 Tons/Year

Product Description

Basic Info

project		unit	index	tolerance
length		m	2050-3100	+/-50
width		m	20-500	+/-0.5
thickness	Aluminum base band	mm	0.150-0.200	+/-0.015
	plastic(EAA)	mm
	Total thickness	mm
Chromium plating amount of aluminum base band		G/ Square meter
Composite strip tensile strength		MPA	≥54
Elongation at break of composite strip		%	>15
Aluminum strip and film showed peeling strength		N/cm	≥6.13
Heat seal peeling strength of composite strip		N/cm	≥17.5
Composite tape water resistance, Peeling strength 68+/-1°C,168h		N/cm	≥6.13
Oil paste resistance of composite tape 68+/-1°C,168h	Umbrella plate	---	unstratified
	WT-103	---
Dielectric strength of composite tape DC 24KV ,1min		---	non-breakdown
Corrosion resistance of composite tape 0.1mol/L,NaOH.480h		Level	≥Level 7
Heat seal shear strength of composite strip	There is no shear failure between plastic layers

Product Description1. ELE type aluminum-plastic composite strip is coated with ethylene - methacrylic acid copolymer (EMAA) resin on the second side of aluminum base strip A and B to achieve a certain bonding degree, and the color is natural or blue;2. EL type aluminum-plastic composite strip is coated with ethylene - methacrylic acid copolymer (EMAA) resin on side A of aluminum base strip, to achieve a certain degree of adhesion, color is natural or blue;3, the process is hot paste method;4. The thickness of ELE type aluminum-plastic composite strip is 0.25 and 0.30;5. The alloy is in O state and the model is 8011 or 1145.Specifications and performance indicators:Appearance: straight, smooth, uniform without impurities, wrinkles and spotsspecificationLength m: 2050-3100Width mm: 20-500Thickness baseband mm: 0.200±0.02, 0.150±0.015Film mm: 0.058±0.013Composite belt mm: 0.32±0.042, 0.27±0.042Tensile strength Mpa: ≥54Elongation of fracture % : ≥15Peeling strength N/cm: ≥6.13Heat seal peeling strength N/cm: ≥17.5Heat seal shear strength: No shear failure occurs between plastic layersWater resistance, peeling strength (68±1ºC, 168h) N/cm: ≥6.13Oil paste resistance (68±1ºC, 168h) : no stratificationDielectric strength (24KV, 1min) : No breakdownCorrosion resistance (0.1mol/L, NaOH, 480h) : Grade ≥7Note:1. The model of aluminum-plastic composite belt is ELE, and the color is natural;2, the tube core is steel core or plastic core, φ75, φ150;3, wooden pallet packaging, steel belt fastening packaging, plastic film moisture-proof.Detailed photo

About us
Jiangsu Chenfeng is a supplier of optical cable and aluminum foil materials with national standard qualification. Its products are widely used in various communication optical cables, cables, submarine optical cables, control cables, signal cables, track cables and air-conditioning condensers, as well as magnetic devices and hot water pipes. Flexible packaging and other fields.Jiangsu Chenfeng has been designated in a number of orders from various telecom operators. Relying on its excellent product quality and perfect service, it has established a good reputation among telecom operators such as China Telecom, China Unicom, China Mobile and China Netcom. At the same time, it actively participates in international competition and has established many partners in the field of optical communication raw materials in the world, becoming an important supplier in the field of global communication and magnetic devices.Jiangsu Chenfeng is a metal-plastic composite belt industry in China. One of the enterprises with large annual output is a trusted partner of global users.Logistics service

Why choose us?Jiangsu Chenfeng is a metal-plastic composite belt industry in China. One of the enterprises with large annual output is a trusted partner of global users.Our goal is to provide one-stop aluminium foil materials solution for global customers, and persistently pout our every effort to achieve this goal.
What can we supply?
We are committed to the research, development and production of aluminum-plastic composite tape for optical cable, with mature technology and first-class service
Thickness baseband mm: 0.200±0.02, 0.150±0.015Length m: 2050-3100How long is per roll? What's the net weight of per roll?
Size of the roll is customized. We will produce as customer request. The estimated net weight can be counted according to foil's thickness, width and length.Packing Method:Each roll shall be suspended at both sides of the wooden box. Rolls shall be wrapped with EPE as first layer coupled with silicon gel desiccant in both sides of roll to protect from corrosion, PE film as 2nd layer and then another layer of PE film for enhancing protection.
FAQ:
Q: Are you a trading company or manufacturer?
A: we are a manufacturer with more than 10 years history in this industry
Q: What is your terms of payment ?
A: Normally 30% TT in advance, balance paid before shipment. If you want other terms, please feel free to let us know in your inquiry
Q: How long does it take for samples and mass production?
A: Usually it will take 15-20 days for new molds and free samples (within 5 kg) after confirmation, 25-30 days for mass production
Q: OEM/ODM available?
A: Yes,we can!Q: Could you provide sample?
A: Yes, We are honored to offer you samples for quality check
Q: Is sample order accepted?
A: Yes,we accept sample order and we can provide design service! Q:Can you offer certificate of origin?
A: Yes, we can offer CO, FTA, Form A, Form B, Form E etc based on your requirements
Q:How can you guarantee the quality?
A: We have complete test systems from raw materials to finished products, each step must be checked and signed by our professional teams.
Q:Can we visit your factory?
A:Yes sure, we sincerely welcome you to visit us at any time!Q:If I only need small quantity, can you produce?
A: Dear customer, because the minimum order quantity of aluminum-plastic composite tape is 2 tons to 5 tons.
